Embodied carbon represents the accumulative emissions a particular material or product generates throughout its lifetime, from manufacturing stage to installation during construction, maintenance and disposal at its end of life.
Classified as critical infrastructure buildings, data centres are required to meet high levels of security, performance and insurance conditions, thus having to rely on traditional high performing, durable materials such as concrete, steel and aluminium – amongst the highest in embodied carbon content.
As material specifiers, we engage with stakeholders in the supply chain to stay up to date with advances to manufacturing processes of traditional materials and to encourage a growing portfolio of lower carbon alternatives. We analyse embodied carbon data from EPD certificates and prioritise reduced upfront carbon (A1-A5) and circularity whenever possible.
studioNWA has also developed ECMat, its own carbon management tool to produce project case studies and to benchmark embodied carbon of materials as we continue to improve our carbon-conscious spec.
Measure. Monitor progress. Push for change. That’s studioNWA‘s approach to advancing Net Zero.
Life Cycle Assessment Stages: BS EN 15978:2011
“Fabric first” approach optimises thermal performance of the building envelope to reduce energy use demands from the outset of the design process.
In data centre typologies, this methodology is particularly effective for the design of administration blocks, as daylighting and views out are an inherent requirement for office areas with permanent workstations, meeting rooms and amenity spaces.
Glazing ratios and solar shading devices designed to suit solar orientation ensure the building façade becomes more resilient to excessive heat gains and losses.
In addition, the optimisation of U-values in external walls, roofs and floors, and effective airtightness details result in a thermally efficient building envelope that reduces Energy Use Intensity (EUI) per square metre and associated carbon emissions.
studioNWA continues to invest in its own sustainability capabilities, including software that can provide real-time design feedback on elements that affect thermal performance of the building fabric. Our design toolkit can also assist the team to identify optimal areas for the installation of solar panels, based on incident solar irradiation values on horizontal and vertical planes.
studioNWA’s early stage design approach facilitates coordination with other disciplines and alignment of energy model targets, contributing to reduction of energy consumption and associated carbon emissions.
Urban greening has become more prevalent as a planning requirement in urban settings, where contributions can be made in the form of green roofs, green walls and amenity areas.
studioNWA engages with Local Planning authorities and specialists to identify the best solution for a given project site to mitigate heat island effect, air pollution, rainwater storm management and
contribute to on-site carbon capture, whilst meeting relevant policy targets.
studioNWA is committed to a carbon management plan to reduce operational carbon emissions, in line with the UK and global Net Zero target by 2050 to limit the effects of climate change.
The framework:
Scope 1 is defined as direct emissions from the combustion of fuel in assets a company operates.
How we are improving – The Old Dairy – our office building in Redbourn- is equipped with an underfloor system for space heating needs. Due to its semi-rural location, the property is not
connected to a natural gas network and relies on an LPG tank to fuel a boiler.
Since 2019, our baseline reporting year, we have managed to reduce our CO2 emissions from heating by 36% by investing in maintenance to the underfloor heating and boiler. We have also
adjusted our thermostat and sealed drafts to further reduce unnecessary heat loss.
Next steps – installation of an air source heat pump to decarbonise our heating supply, replacing LPG gas combustion on site for electricity.
Scope 2 refers to indirect emissions from the generation of energy purchased from a utility provider.
How we are improving – since we began monitoring our electricity consumption, we have become more rigorous about light switches being turned off after meetings and in office areas not being occupied. Sensors have been installed in the kitchen and toilets. A post-pandemic hybrid work mode requires PCs being left on for longer periods of time, which reflects in the 6% electricity use increase in 2022, also attributed to additional IT equipment due to growing staff numbers. Mitigation measures are in place, such as energy saving monitors and switch-off schedules when possible. We also continue to benchmark Electricity Use Intensity (EUI) in kWh/m2 against CIBSE’s Database for similar office typologies in both typical and good practice consumption scenarios.
Next steps – proposal for a roof mounted solar panel system to go through planning to seek consent for on-site renewable energy production, reduce reliance on the national grid and associated CO2 emissions.
Scope 3 includes indirect emissions from transport, purchase of goods, business travel and other relevant upstream and downstream emissions.
How we are improving – commuting to the office plays a big role in our operational carbon emissions, as our semi-rural location is not accessible by public transport.
One of the lessons learned from the Covid-19 pandemic was that our business was able to adjust to remote working conditions and continued to thrive. A lesson that we took on board as we continue to operate in hybrid mode, reducing the number of car trips to the office and in some cases allowing staff to work remotely from international posts on a permanent basis.
Commuting flexibility has translated into a 51% reduction of carbon emissions from miles travelled when compared to 2019, our baseline year.
We also encourage video calls for meetings and prioritise travel by rail rather than flying.
Next steps – the installation of electrical vehicles charging stations to promote a cleaner mode of transport to the office.
To extend the monitoring of Scope 3 emissions to business travel, hotel stays, waste and other relevant categories.
BREEAM & LEED assessments are the leading and most widely adopted environmental assessment methods for data centre buildings today, often pursued at planning stage and to reinforce client’s ESG goals.
studioNWA’s in-house knowledge of these certification schemes allows us to work closely with our clients, sustainability consultants and wider design team to maximise the potential for architecturally-driven credits and meet project targets.
Implementation of green roof and walls for a number of benefits:
